Draftsman's updated transitional form ties perfectly into any space while delivering superior performance. Matte White and Matte Black finish options enhance Draftsman's industrial-inspired design to complement indoor and outdoor spaces alike. With integrated LED and DC motor technology, Draftsman delivers excellent energy efficiency. For lower ceilings, a flush mount kit is an accessory option for easy customization. Operated by the HIRO control or WiFi-compatible with the Hinkley app.
Additional Details:
Category:
Fan
Finish:
Matte White
Style:
Industrial
Family:
Draftsman
Glass:
White Frosted
Voltage:
120 V
Number of Bulbs:
1 Bulbs
Air Flow Efficiency:
9902
Amperage:
0.52
Blade Finish:
Matte White
Blade Pitch:
12
Blade Span:
72
Blades Included:
Yes
Bulb Dimmable:
Yes - CL Type Dimmer (SSL7A)
Bulb Hours:
50000
Bulb Type:
LED
Canopy:
6.5 Dia. x 2.5 D
Introduction Date:
01/01/2023
Kelvin:
3000
Light Kit Included:
Yes
Lumens / Light Output:
1320
Material:
Steel
Motor Size:
DC 155 x 22 (Ferrite)
Motor Type:
DC
Ship Carton Height:
9
Ship Carton Length:
34
Ship Carton Width:
17
Ship Weight:
35
Vendor Ship Method:
Parcel
Weight:
28
Airflow Avg:
7348
AMPS Avg:
0.31
Avg Energy Use:
24
Blade Material:
Aluminum
Blade Options Available:
No
Blade To Ceiling Height:
12.75
Blades Reversible:
No
Bulb CRI:
90
Bulb Included:
Yes
Control Type:
HIRO Control - 6 Speed Reversing
Country of Origin:
China
Dual Mount:
No
Efficiency Avg:
305
Efficiency High:
294
Energy Cost Avg:
7
Energy Cost High:
9
Energy Use High:
33.7
Fan Control:
Yes
Flush Mount Fan:
No
Incandescent Equivalency:
100 W
Light Kit Adaptable:
No
Light Source:
Integrated LED
Location Rating:
Wet Rated
Max Wattage:
16 W
Motor Fan Speed:
6
Number of Blades:
6
Operating Frequency:
60
Prop 65 Description:
CALIFORNIA PROP 65: WARNING: This product can expose you to chemicals including lead which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Receiver Included:
Yes
Reversing Control:
Yes
Rpms Avg:
82
RPMS High:
112
Safety Rating:
UL Approved, C-US Approved
Single Power Switch:
No
Slope:
20
Sloped Ceiling Adaptable:
Yes
Stand By Power:
0.2
Style-2:
Transitional
Title 24:
No
WIFI Control Included:
Yes
WIFI Control Optional:
No
Standard Category:
Exterior
, Fans
Standard Subcategory:
Exterior Fans
, Ceiling Fans with Light
Standard Finish:
White
Standard Style:
Transitional
, Industrial
Standard Option:
Wet Rated
, Prop 65
Standard Voltage:
100-120
Standard Lumens:
1101-1600
Standard Number of Blades:
6 Blades
Standard Kelvin:
2501-3000
Standard Location Rating:
Wet Rated
Family:
Draftsman
